Model AW1020-100 AW1710-100 AW3200-100
Panel Type TFT LCD TFT LCD TFT LCD
Viewing Area 10.2′ 17.1′ 32′
Resolution RGB 800 X 480 WXGA 1268 X 768 WXGA 1366 X 768
Ratio 16:9 16:9 16:9
Response Time 12ms 12ms 8ms
Contrast Ration 300 Typ 400 Typ 400 Typ
Luminance 400 Nits 450 Nits 450 Nits
L/R Viewing Angle 60° / 60° 85° / 85° 85° / 85°
U/D Viewing Angle 50° / 60° 85° / 85° 85° / 85°
Lamp Life 20,000 hours 50,000 hours 50,000 hours
Power 10W (max.) 35W (max.) 105W (max.)
Voltage 115V / 400Hz 115V / 400Hz 115V / 400Hz
Weight 7 Lbs 10 Lbs 30 Lbs
Dimensions TBD 10.82′ (H) X 15.88′(W) X 2.20′(D) 18.31′ (H) X 30.52′(W) X 2.70′(D)

In-Seat Power System

LED Lights
